Switch Gestionable D-Link DGS-1100-08V2 8 Puertos/ RJ-45 10/100/1000

Marca	D-Link
Modelo	DGS-1100-08V2/E
Especificaciones	- 8 puertos 10/100/1000 Mbps Funcion de los puertos - IEEE 802.3 para Ethernet - IEEE 802.3u para Fast Ethernet - IEEE 802.3ab para Gigabit Ethernet - Autonegociación - Admite operación de dúplex medio / completo (la mitad a 10/100 Mbps, completo a 1000 Mbps) - Auto MDI / MDIX - IEEE 802.3x Flow Control admite el modo full-duplex - Cumple con IEEE 802.3az Rendimiento: 16Gbps - Max.velocidad envío 11.9 Mpps - Tamaño tabla MAC 8K Entries - Packet Buffer 1.5Mbits - Modo envío: Store and Forward - Alimentación: 100 to 240 VAC, 50 to 60 Hz - Max.Consumo 4.94 Watts - Consumo Standy 1.93 Watts - Sin ventilador - Nivel acústico: 0 dBA - Dimensions (W x D x H) 145 x 82 x 28 mm - Peso: 0.34kg - LEDs Power (Per Device) PoE Max. (DGS-1100-08P Only) Link/Activity/Speed (Per Port) - Certifications FCC Class A CE Class A VCCI Class A - Vertificaciones UL/cUL CE LVD - MTBF 503,585 Hours (DGS-1100-08) - VLAN Port-based VLAN 802.1Q Tagged VLAN Surveillance VLAN Voice VLAN Management VLAN VLAN Group Soporta 32 static VLAN groups Max. 4094 VIDs - Funciones L2 Flow Control 802.3x Flow Control HOL Blocking Prevention IGMP Snooping IGMP v1/v2 Snooping Soporta 32 Groups Loopback Detection Link Aggregation 2 groups, 2-4 ports per group (DGS-1100-08/08P) Port Mirroring One-to-One Many-to-One (DGS-1100-16/24 only) Cable Diagnostics Statistics Tx Ok Tx Error Rx Ok - Rx Error - QoS 802.1p Quality of Service 4 queues per port Queue Handling Strict Weighted Round Robin (WRR) - Bandwidth Control - DGS-1100-05/08/08P Port Based (Ingress/Egress, min. granularity 8 kb/s) - Seguridad Static MAC Address Max. 32 entries (DGS-1100-05/08/08P) Broadcast/Multicast/Unknown Unicast Storm Control - Gestíon Web-Based GUI (Soporta IPv4) Smart Console Utility - D-Link Green Power Saving by Link Status Cable Length Energy Efficient Ethernet (IEEE 802.3az) RoHS Compliant - RFC Standard List RFC 768 UDP RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 951 BootP Client RFC 1542 BootP/DHCP client RFC 1945 HTTP/1.0 RFC 2647 802.1p - No Incluye enchufe británico
Fecha de revisión	27-10-2022 por MPM
